84 | BEP CZone
CZone system overview options
Enables you to monitor all on board parameters including tank levels displayed in
graphical, percentage and volume remaining formats.
Shows control options and monitoring information.
Displays visual and audible alarms that can be set for high and low levels.
The BEP CZone info panel
When the CZone is installed and configured, an additional CZone dashboard will be
added to the Instrument panels.
Vessel dashboard Navigation dashboard Angler dashboard CZone dashboard
You switch between a panel’s dashboards by using the left and right arrow keys or by
selecting the dashboard from the menu.
Editing the CZone dashboard
You can customize CZone dashboard by changing the data for each of the gauges.
Available editing options will depend on the type of gauge selected for editing, and which
data sources are connected to your system. Refer to the Info panel section.
