56 | StructureScan
When the StructureScan image is being recorded, there will be a flashing red symbol and
a logging message will appear periodically at the bottom of the screen.
The graphics below shows that both conventional echo-sounder and StructureScan data
are being logged.
RECORDING
SYMBOL
LOGGING
MESSAGE
The sounder recording is stopped by repressing the MENU key.
Viewing the recorded sounder data
Both internally and externally stored sonar records may be reviewed when selected.
MENU WIN
x2
