4Technical data Sirona Dental Systems GmbH
4.1Operating, transport and storage conditions Service Manual INTEGO / INTEGO pro
4.1
Operating, transport and storage conditions
Mode of operation
Operating and transport conditions
Load capacity of the patient chair
Media pressures and flow rates
Mode of operation Continuous operation with intermittent
loading corresponding to the dental
mode of working.
Drive motors for chair operation:
intermittent use, max. 2 minutes on and
18 minutes off
Permanently connected unit. Operation
is not permitted in mobile vehicles.
Transport and storage
conditions:
Temperature: -40 °C – +70 °C
(-40 °F – 158 °F)
Relative humidity: 10% – 95%
Air pressure: 500 hPa – 1,060 hPa
Operating conditions: Ambient temperature: 10 °C – 40 °C (50
°F – 104 °F)
Relative humidity: 30% – 85%
no condensation
Air pressure: 700 hPa – 1,060 hPa
Installation location: ≤ 3000 m above sea level
This treatment center is not suitable for
operation in areas subject to explosion
hazards.
Pollution degree: 2 acc. to IEC 60664-1
-40
+70
1060
500
95
10
+10
+40
1060
700
85
30
Load capacity of the patient
chair:
140 kg (308.6 lbs) or 185 kg (407.9 lbs),
depending on the model
The max. load capacity is indicated on a
sticker next to the rating plate of the
treatment center.
Local pressure (min./
max):For details see page
Requirements of the supply
media
Air: 5.5 / 7.5 bar
Water 2.5 / 6 bar
Suction air: p
u
min. 0.12 bar (1.7 psi),
max. 0.18 bar (2.6 psi)
≥ 500 l/min
Water flow:
For details see page
Requirements of the supply
media
Water absorption max. 3 l/min
Residual water max. 3 l/min
