6Overview of modules and boards Sirona Dental Systems GmbH
6.3Dentist element Service Manual INTEGO / INTEGO pro
Measuring points
Function of the board
Function of the board
● The 18 buttons are detected by means of resistive sensors.
Measuring point Function
3V3 Voltage measurement
GND Voltage measurement
Source Destination Location Function
X1 X2 DAB Dentist Element Power supply and communication
