64 57 316 D3543
64 D3543.076.01.04.02 06.2015
6Overview of modules and boards Sirona Dental Systems GmbH
6.3Dentist element Service Manual INTEGO / INTEGO pro
Connector
Function of the board
Activation of:
● Sprayvit (LED instrument light only)
● Turbine (LED instrument light only)
● Motor 1 (the instrument light for one of the turbines can also be
connected here)
● Motor 2 (the instrument light for one of the turbines can also be
connected here)
● Mini LED
Source Destination Location Function
X5 Mini LED - Mini LED
X8 X8 DAP Dentist Element APEX, light
X9 X9 DAP Dentist Element Power supplies, CAN, Apex on, motor
detection, turbine detection, Mini LED
X10 X10 DAP Dentist Element APEX motor control
X11 Sprayvit with LEDlight Dentist element flange Sprayvit with LEDlight
X12 High-speed handpiece 3 Dentist element flange Control light for high-speed handpiece 3
X13 Motor 1 or high-speed
handpiece 1
Dentist element flange Control light for motor 1 or high-speed
handpiece 1
X13.1 Motor 1 Dentist element flange Activation of motor 1
X14 Motor 2 or high-speed
handpiece 2
Dentist element flange Control light for motor 2 or high-speed
handpiece 2
X14.1 Motor 2 Dentist element flange Activation of motor 2
IMPORTANT
The board DAR is envisaged for operating 2 dental motors.
If it is necessary for several high-speed handpieces to be configured
with board DAR, the plug-in connectors X13 or X14 must be used to
supply light to these high-speed handpieces. Additional information can
be found in chapter Connecting the motors and turbines in the dentist
element [ → 35].
