6Overview of modules and boards Sirona Dental Systems GmbH
6.3Dentist element Service Manual INTEGO / INTEGO pro
Measuring points
Function of the board
Function of the board
Activation of:
● Turbine LED for 3 turbines
● Turbine third-party manufacturer LED for 3 turbines
● Sprayvit LED
Measuring point Function
36 V Voltage measurement
GND Voltage measurement
Source Destination Location Function
X5 X6 DAB Dentist element Dentist element control
X1 DAP Dentist element Instrument control
X4 DAPm Dentist element Instrument control
X11 SPRAYVIT Dentist element flange Instrument light
X12 Turbine 1 Dentist element flange Instrument light
X13 Turbine 2 Dentist element flange Instrument light
X14 Turbine 3 Dentist element flange Instrument light
