64 57 316 D3543
D3543.076.01.04.02 06.2015
73
Sirona Dental Systems GmbH 6Overview of modules and boards
Service Manual INTEGO / INTEGO pro 6.3Dentist element
båÖäáëÜ
Measuring points
Connector
Function of the board
● Communication via CAN with the DAR
● Supply for instrument light (LED only)
● Activation of scaler handpiece
● Via the DAR board: Mini LED power supply
BOOT yellow Lights up after switching on and remains lit until completion of the boot
process
INSTR yellow Off: Instrument deposited
Flashing:
1x Sprayvit
2x Turbine 1
3x Turbine 2
4x Turbine 3
5x Motor 1
6x Motor 2
7x Scaler
8x Polylight
INST_ACTIVE yellow Motor/Sirosonic active (output stage)
LIGHT yellow Instrument light activated
FS_ACTIVE yellow Foot control signal active
Measuring point Function
CAN+ Terminating resistor measurement
CAN- Terminating resistor measurement
36V Voltage measurement
GND Voltage measurement
Source Destination Location Function
X2 Sirosonic TL Dentist element flange Instrument control
X3 Sirosonic TL Dentist element flange Instrument light
X9 X9 DAR Dentist Element CAN, Mini LED, APEX, instrument control
LED Color Function
