Sirona Dental Systems GmbH 6Overview of modules and boards
Service Manual INTEGO / INTEGO pro 6.3Dentist element
båÖäáëÜ
Overview of Apex DARWIN
NAH - Apex mucosal electrode
Components on the board
Connector
Function
Function of the NAA board
The NAA board is integrated into the work station via CAN and is used for
Apex measurement.
Source Destination Location Function
X1 Apex lip clip/file clamp Dentist element
X2 X6 NAA Dentist element
