Sirona Dental Systems GmbH 6Overview of modules and boards
Service Manual INTEGO / INTEGO pro 6.4Water unit
båÖäáëÜ
Function pads
Measuring points
Connector
Function pads Function
ASE_SUC Switch ON (removal of suction on assistant element)
DS30 Reed_Sep
DS Start suction machine in order to empty the cuspidor valve
S52 Start flushing for suction hose cleaning
Measuring points Function
36 V Voltage measurement
GND Voltage measurement
21 V Voltage measurement
35 V Voltage measurement
12 V Voltage measurement
Source Destination Location Function
X1 Holder 2, holder 3, holder 4 Comfort assistant element Removal detection
Holder 2, holder 3, holder 4 Compact assistant element Removal detection
X2 MSBV (Dürr wet suction
system)
Water unit Control of cuspidor valve
X2 Motor (separation only) Water unit Control of separation motor
X12 MV33 Water unit Control of place selection valve
X13 Reed switch DS30
Reed switch DS
Water unit Level detection for separation tank
Level detection for cuspidor valve
X14 Taste Clean Switch (cuspidor
valve)
Water unit Empty cuspidor valve
X15 S52
MV52
Water unit Control of flushing for suction hose
cleaning
X21 X10 DSA Patient chair Removal detection, separation control,
power supply
X30 X30 DSA Patient chair SCOM, CAN, foot switch, power supply
X31 X30 DAB Dentist Element SCOM, CAN, foot switch, power supply
X44 Suction_pump Water unit Control of suction pump
