Sirona Dental Systems GmbH 6Overview of modules and boards
Service Manual INTEGO / INTEGO pro 6.6LEDview
båÖäáëÜ
Connector
DARWIN function
Function of the board
● Control the LEDview.
● Communication with other PCBs via CAN.
● Evaluation of the NoTouch sensor.
● Brightness settings via software.
Source Destination Location Function
X1 X45 DWE Water unit Power supply
X45 DWEm Water unit Power supply
X45 DWB Water unit Power supply
X45 DWV Water unit Power supply
X2 X45 DWE Water unit CAN
X45 DWEm Water unit CAN
X45 DWB Water unit CAN
X45 DWV Water unit CAN
X2 x1 NLL LEDview Power supply LEDs
X3 x1 NLL LEDview Power supply LEDs
X4 x1 NLL LEDview Power supply LEDs
X6 NoTouch sensor LEDview Brightness control
