Skipper GDS101 User Manual

Page 55 of 70
Edition: 2014.04.01
Chapter: 6. Specications, Dimensions
6. Specications, Dimensions
Transducer, 38 kHz
Diameter. 181 mm.
Mounting. Tank/sea valve/ice tank.
Cable length. 40 m.
Weight. ca. 20 kg.
Protection. IP 68.
Transducer, 50 kHz Diameter. 90 mm.
Mounting. Tank/sea valve/ice tank/aluminium tank.
Cable length. 25 m or 40 m.
Weight. ca. 7 kg.
Protection. IP 68.
Transducer, 200 kHz
Diameter. 140 mm.
Mounting. Tank/ice tank.
Cable length. 25 m or 40 m.
Weight. ca. 8 kg.
Protection. IP 68.
Transducer, 200 kHz
Diameter. 90 mm.
Mounting. Tank/sea valve/ice tank/aluminium tank.
Cable length. 25 m.
Weight. ca. 7 kg.
Protection. IP 68.
Transducer Junction Box
Size incl. glands. 132 x 111 mm.
Depth. 55 mm.
Weight. 0.6 kg.
Protection. IP 56.
Operator unit cabinet
Height, front. 340 mm.
Width. 320 mm.
Depth. 170 mm.
Weight. ca. 10 kg.
Protection. IP 42.
GDS101 Operation and Installation
SKIPPER Electronics AS
