Skipper GDS101 User Manual

Page 57 of 70
Edition: 2014.04.01
Chapter: 6. Specications, Dimensions
Environmental according to IEC60945:
Transducer and Junction Box
Operating temperature.
-15 - 55 degree C IEC 60945.
Storage temperature.
-20 - 70 degree C.
Protection, transducer.
6 bar, IP 68.
Protection, junction box.
IP 56.
Operator Unit Cabinet
Supply voltage.
230 V (195 - 253 V AC) or 115 V (96 - 125 V AC).
24 V DC (20 - 32 V).
Power consumption.
50 W at 24 V, 70 W at 230 V AC or 115 V AC.
Alarm relay.
Change-over contact, max. 24 V 300 mA.
RS-232 C port.
Standard 25 pin D - type connector (located on terminal PCB inside cabinet).
NMEA port.
9 pin D - type. 2 inputs, 2 outputs.
Operating temperature.
-15 - 55 degree C according to IEC60945.
To increase serviceability and life-time, we suggest the working temperature to be held
at 0 - 40 degree C.
Storage temperature.
-20 - 70 degree C.
Humidity.
10 - 90 % relative, no condensation.
Protection.
IP 42.
Measuring accuracy
Better than 1 %.
GDS101 Operation and Installation
SKIPPER Electronics AS
