Chapter: 9. Appendix, Miscellaneous Drawings
9. Appendix, Miscellaneous Drawings
For repeater and repeater dimmer, see separate manual: IR301 manual
For tank and sea valve, see separate manuals:
ETNSLJB-manual. Single bottom sea valve (discontinued from 2007).
SB-100-manual. Single bottom sea valve.
DB-100-manual. Double bottom sea valve.
SB-200-manual. For 24 and 38 kHz transducer deep sea.
Standard tank inst manual. For 50 and 200 kHz transducer.
Combo tank inst manual. For 24 and 38 kHz transducer deep sea. For different type of transducers, custom design is
possible.
All manuals (examples below) available on manufacturers homepage. (See title page for details).
