Skipper GDS101 User Manual

Page 56 of 70
Edition: 2014.04.01
Chapter: 6. Specications, Dimensions
Functional Properties
Display.
10,4” 158 x 211 mm graphic LCD screen with adjustable day/night vision and backlight. 640 x
480 pixels.
Printer.
HP Deskjet, Epson D88 or Epson LQ300.
Depth alarms.
Deep and shallow limits.
Calendar/Clock.
Year-month-day/hours-minutes-seconds (24 hour system).
Interface outputs.
Transmitter trigger pulse and bottom pulses.
Analogue 4 - 20 mA and 0 - 10 V for depth. Detected video.
IEC 61162-1:2007(E) (NMEA 0183) for alarm and depth.
Alarm relay.
Output for VGA repeater.
RS-232 C.
PC parallel printer port.
Interface inputs.
100/200/400/20000 pulses for speed.
IEC 61162-1:2007(E) (NMEA 0183) for speed, position, alarm, heading and time.
Remote alarm reset.
Remote transducer selector.
Languages.
English, French, Spanish, Russian, German and Norwegian.
Options.
VDR (Voyage Data Recorder) or IR301 digital remote depth indicator.
LCD repeater.
Remote keyboard.
Remote sounding control.
Autorange.
Sound speed calibration.
Performance
Depth range.
0 - 1600 m.
Graphic resolution.
0.5 % of range.
Digital screen resolution.
<10 m: 0.01 m.
>= 10 m <100 m: 0.1 m.
>= 100 m: 1 m.
Transducer, 24 kHz/38 kHz.
Beam angle. 16°/20° conical.
Max. power. 24 kHz = 1.5 kW/38 kHz =1.0 kW.
Effective range. 3000 m/1500 m.
Transducer, 50 kHz.
Beam angle. 33° conical.
Max. power. 1 kW.
Effective range. 750 m.
Transducer, 200 kHz.
Beam angle. 6° conical.
Max. power. 1 kW.
Effective range. 350 m.
Transducer, 200 kHz.
Beam angle. 10° conical.
Max power. 1 kW.
Effective range. 350 m.
GDS101 Operation and Installation
SKIPPER Electronics AS
