Electronic Controller
Service Manual
SKOPE TME/SKT ActiveCore
Parameter list – Program 101: ActiveCore Series S4 EVO (continued from previous
page)
Revision: 2.0
Application
ActiveCore Top & Bottom Mount
Controller Type
SKOPE S4 EVO
Controller Model & Revision
PZSKC0H002K (Rev 1.414)
SKOPE Part Number
ELZ11478-101
Setting Unit
SET0 Min Max
Parameter
101
CPS1017-101-SET0
Last revised on
7-Dec-2017
Full List
SET0
Access
Level
Range
Description
Electronic Controller Parameter Sheet
d/2 - °C F - -
Probe reading on 3rd Input (read only)
d10 -50.0 °C C -50.0 127
On demand defrost Start Temperature
d11 0 mins C 0 60
On demand defrost: start delay
d12 127 °C C -50.0 127
Enabling defrost condition: Control probe threshold
d13 1 C01
Evaporator Fans During Defrost (0 = Off 1 = ON)
d19 200 mins C 0 200
No Downward Tendency Defrost - Start Delay (0 = function disabled)
d20 20 mins C 1 < d19
No Downward Tendency Evaluation (Sample Time)
d21 1 C05
Number of NDT defrosts before R.S.F. "Err" alarm (0 = function disabled)
d22 0.1 °C C 0.0 5.0
No Downward Tendency Evaluation (Temperature Delta)
Alarm & Input Configuration Parameters
A0 2.0 °C C -20.0 20.0
Temperature Alarm Differential
AL 4.0 °C C -50.0 150
Low temperature alarm setpoint. (Relative if A0>0, Absolute (A0≤0)
AH 8.0 °C C -50.0 150
High temperature alarm setpoint. (Relative if A0>0, Absolute (A0≤0)
Ad 180 mins C 0 199
Temperature alarm delay ( 0 = AL and AH alarms disabled)
A10 2 mins C 0 10
Door Open Alarm delay (0 = door open alarm disabled)
A11 1 C05
2nd Input Configuration
A12 3 C016
Number of cA alarm events to trigger manual reset 'CA' alarm
A13 24 hrs C 0 240
cA alarm counter reset delay
A14 60 mins C 0 240
cA alarm reset delay
A15 1 C01
Lights switched OFF when CHt, cA or CA alarm occurs
A18 1 C01
Allow power cycle to reset CA alarm
A20 4 mins C A10 60
Faulty door/curtain switch E2 alarm delay
Ac 70.0 °C C -50.0 250
High condenser temperature alarm set point
AE 5.0 °C C 0.1 20.0
High condenser temperature alarm differential
Acd 0 mins C 0 250
High condenser temperature alarm delay
Acr 1 C02
High condenser temperature alarm reset method
A21 2 C05
3rd Input Configuration
Evaporator Fan Parameters
F0 3 secs C 1 100
Loads Activation Delay
Fd0 20 mins C 1 100
Fan DAY Duty Cycle : ON time
FdF 0 mins C 0 100
Fan DAY Duty Cycle : OFF time
Fn0 2 mins C 1 100
Fan NIGHT Duty Cycle : ON time
FnF 2 mins C 0 100
Fan NIGHT Duty Cycle : OFF time
Other Parameters
H0 1 C0207
Supervisor Serial address
H01 1 C01
Baud Rate (0 = 9600, 1 = 19200)
H02 2 C02
Stop Bits
H03 0 C02
Parity ( 0 = None, 1 = Odd, 2 = Even)
H2 1 C03
Enable Keypad
H4 0 C01
Disable buzzer (0 = Buzzer Enabled, 1 = Buzzer Disabled)
H5 101 F0199
ID code (read-only)
Warning
1. Only make program modifications with reference to relevant Operating Manual.
2. This programming sheet is exclusively for SKOPE refrigeration systems with its dedicated Carel controller.
3. Any alteration from this program may adversely affect the SKOPE Refrigeration System operation.
4. Specification may change without notice. Please check with SKOPE Customer Service for latest revision.
Page 2 of 2
