Parameter list – Program 101: ActiveCore Series S4 EVO (continued over page)
Revision: 2.0
Application
ActiveCore Top & Bottom Mount
Controller Type
SKOPE S4 EVO
Controller Model & Revision
PZSKC0H002K (Rev 1.414)
SKOPE Part Number
ELZ11478-101
Setting Unit
SET0 Min Max
Probe Parameters
PS 22 F0200
Password (Read Only)
/2 4 C115
Measurement stability (Applies to all probes)
/4 1 C15
Select probe displayed
/5 0 C01
Select °C/°F ( 0=°C ; 1=°F )
/6 0 C01
Disable decimal point
/8 0.0 °C C -99.00 99.0
Display Offset (Only if /E > 0)
/9 0.0 °C C -40.0 /A
Minimum Display value (Only if /E > 0)
/E 1 C050
Display Dampening Coefficient
/C1 0.0 °C C -50.0 50.0
Probe 1 Calibration Offset
/C2 0.0 °C C -50.0 50.0
Probe 2 Calibration Offset
/C3 0.0 °C C -50.0 50.0
Probe 3 Calibration Offset
Regulation Parameters
St 2.0 °C F r1 r2
Set point
rd 2.0 °C C 0.0 19.0
DAY differential
r1 1.0 °C C -50.0 r2
Minimum set point value
r2 15.0 °C C r1 150
Maximum set point value
r3 1 C01
Enable Auto Day/Night Mode Switching
r4 1.0 °C C -50.0 50.0
Night Mode set point delta (added to St)
r5 2.0 °C C 0.0 19.0
Night differential
r6 3 hrs F 0 90
Night Mode Start Delay (time period with no door openings)
r7 9 hrs F 1 90
Night Mode Timeout (time period in night mode)
r10 0 hrs C 0 24
Light Delay On Time after entering DAY mode
Cold Climate Protection Parameters
CCt 2.0 °C C 0.1 20.0
Cold Climate Protection Temperature Delta
CCd 30 mins C 0 199
Cold Climate Protection Delay
Pull Down Mode Parameters
Pt 127 °C C 0 127
Pull-down Mode - Activation Temperature
Pd 250 hrs C 0 250
Pull-down Mode - Maximum Duration
Compressor Parameters
c0 1 mins C 0 200
Comp. and Fan start delay at power-up.
c1 0 mins C 0 100
Minimum time between consecutive compressor starts
c2 5 mins C 0 100
Minimum compressor off time
c3 5 mins C 0 100
Minimum compressor on time
c4 7 mins C 0 100
Compressor on time with duty setting
c5 1 C01
Enable mains voltage protection (0 = disabled, 1 = enabled)
Defrost Parameters
d0 0 C01
Type of defrost ( 0 = Electric, 1 = Hot Gas)
dI 2 hrs C 0 199
Defrost interval time (Time between defrosts)
d2 1 C01
Run defrost interval timer only when compressor running
dt 4.5 °C C -50.0 127
Defrost Termination temperature
dP 90 mins C 1 199
Maximum defrost duration
d4 1 C01
Defrost request at power-on: (0 = no, 1 = yes)
d5 0 mins C 0 199
Defrost delay on power-up (when d4=1)
d6 1 C01
Display during defrost (0 = "dEF", 1 = Temperature at start of defrost)
dd 0 mins C 0 15
Dripping time (compressor and fans stopped after defrost)
d8 0 mins C 0 199
Bypass high temperature alarm after defrost or door opening
d9 0 C01
Defrost priority over compressor protectors
d/1 - °C F - -
Probe reading on 2nd Input (read only)
Parameter
101
CPS1017-101-SET0
Last revised on
7-Dec-2017
Full List
SET0
Access
Level
Range
Description
Electronic Controller Parameter Sheet
Page 1 of 2
