Axles, Drive Shafts, Wheels and Tires
5-5
6036, 6042, 8042, 10042, 10054 31211015
5.2 GENERAL INFORMATION
Note: To help ensure optimum performance, the drive shaft
assemblies are specially balanced as a unit at the factory. When
servicing any flange yoke, slip yoke or drive shaft tube, order a
complete assembly if components are bent or damaged. Refer
to the appropriate parts manual for ordering information.
Before performing any inspection, maintenance or service
operation, thoroughly clean the unit. The axles and drive
shafts should be checked and repaired only by experienced
service technicians who are aware of all safety instructions
and particular component features.
Use suitable products to thoroughly clean all disassembled
mechanical parts to help prevent personal injury to the
worker and prevent damage to the parts. Carefully inspect
the integrity of all moving parts (bearings, yokes, tubes,
gears, shafts, etc.) and fasteners (nuts, bolts, washers, etc.) as
they are subject to major stress and wear. Always replace any
damaged, worn, cracked, seized or otherwise improper parts
that could affect the safe and proper functioning of the
machine, axles and drive shafts.
5.3 AXLE ASSEMBLIES
5.3.1 Axle Serial Number Plate
The front axle serial number plate is located on a mounting
pad on the inboard portion of the right beam trumpet. The
rear axle serial number plate is located on a mounting pad on
the inboard portion of the left trumpet. Information on the
serial number plate is required in correspondence regarding
the axle.
Supply information from the axle serial number plate when
communicating about an axle assembly or axle components.
5.3.2 Axle Specifications
General axle specifications are found in Section 2.3, “Fluid
Specifications”.
5.3.3 Axle Internal Service
Detailed axle service instructions (covering the axle,
differential, brakes and wheel-end safety, repair,
disassembly, reassembly, adjustment and troubleshooting
information) are provided in the appropriate Axle Repair
Manual.
WARNING
DO NOT service the machine without following all safety
precautions as outlined in Section 1, “Safety Practices”, of
this manual.
Machine Manufacturer
Model
Axle PN
6036,6042
212/A02 Front
31200162
212/A03 Rear
Machine Manufacturer
Model
Axle PN
8042 MS-T 3055 II All 31200695
10042,10054 MS-T 3060 II Front 31200694
10042,10054 MS-T 3055 II Rear 31200695
