Hydraulic Section
8-54
31211015 6036, 6042, 8042, 10042, 10054
8.9.4 Cylinder Torque Specifications
a. Lift/Lower Cylinder
b. Extend/Retract Cylinder
c. Tilt Cylinder
d. Frame Level Cylinder
e. Stabil-TRAK Cylinder
Model Head Piston Piston Lock Nut Valve Set Screw
6036, 6042
295lb-ft
(400 Nm)
966 lb-ft
(1310 Nm)
NA
33 - 37 lb-ft
(45 - 50 Nm)
7.4 lb-ft
(10 Nm)
8042, 10042,
10054
300 - 400 lb-ft
(407 - 542 Nm)
NA
1750 - 2000 lb-ft
(2372 - 2556 Nm)
30 - 35 lb-ft
(41 - 47 Nm)
10 - 26 lb-ft
(13 - 35 Nm)
Model Head Piston Valve Set Screw
6036
300 - 400 lb-ft
(407 - 542 Nm)
330 - 390 lb-ft
(447 - 529 Nm)
40 - 50 lb-ft
(54 - 67 Nm)
9 - 11 lb-ft
(12 - 15 Nm)
6042
300-400 lb-ft
(407-542 Nm)
330-390 lb-ft
(447-529 Nm)
40 - 50 lb-ft
(54 - 67 Nm)
9 - 11 lb-ft
(12 - 15 Nm)
8042, 10042, 10054
300 - 400 lb-ft
(407 - 542 Nm)
390 - 460 lb-ft
(529 - 624 Nm)
150 - 160 lb-ft
(203 - 217 Nm)
9 - 11 lb-ft
(12 - 15 Nm)
Model Head Piston Piston Locknut Valve Set Screw
6036, 6042
300 - 400 lb-ft
(407-542 Nm)
240 - 280 lb-ft
(325 - 380 Nm)
NA
30 - 35 lb-ft
(41 - 47 Nm)
9 - 11 lb-ft
(12 - 15 Nm)
8042, 10042,
10054
500 - 600 lb-ft
(678-813 Nm)
NA
1850 - 2000 lb-ft
(2508 - 2712 Nm)
30 - 35 lb-ft
(41 - 47 Nm)
N/A
Head Piston Locknut Valve Plug
300 - 400 lb-ft
(407 - 542 Nm)
1100 - 1250 lb-ft
(1491 - 1695 Nm)
35 - 40 lb-ft
(47 - 54 Nm)
10 - 12 lb-ft
(13 - 16 Nm)
Head Piston Locknut Check Valve Set Screw
Pressure Reducing/PO
Check Valve
Solenoid Coil
300 - 350 lb-ft
(407 - 475 Nm)
1175 - 1400 lb-ft
(1593 - 1898 Nm)
20 - 25 lb-ft
(27 - 34 Nm)
3 - 4 lb-ft
(4 - 5 Nm)
35 - 40 lb-ft
(47 - 54 Nm)
25 - 30 lb-ft
(34 - 41 Nm)
300 - 350 lb-ft
(407 - 475 Nm)
1175 - 1400 lb-ft
(1593 - 1898 Nm)
20 - 25 lb-ft
(27 - 34 Nm)
3 - 4 lb-ft
(4 - 5 Nm)
35 - 40 lb-ft
(47 - 54 Nm)
25 - 30 lb-ft
(34 - 41 Nm)
