Skytrak 8042 - Page 265

Hydraulic Section
8-55
6036, 6042, 8042, 10042, 10054 31211015
f. Compensation Cylinder
g. Swing Carriage Cylinder (If Equipped)
h. Side Tilt Carriage Cylinder (If Equipped)
i. Outrigger Cylinder
Model Head Locknut Valve Set Screw
6036, 6042
250 - 350 lb-ft
(339 - 474 Nm)
650 - 700 lb-ft
(881 - 949 Nm)
30 - 35 lb-ft
(40 - 47 Nm)
3 - 4 lb-ft
(4 - 5 Nm)
8042, 10042,
10054
300 - 400 lb-ft
(407 - 542 Nm)
900 - 1050 lb-ft
(1220 - 1424 Nm)
NA
Model Piston Head Set Screw Valves
6036, 6042
440 - 500 lb-ft
(597 - 678 Nm)
250 - 350 lb-ft
(339 - 474 Nm)
85 - 95 lb-ft
(115 - 129 Nm)
30 - 35 lb-ft
(41 - 47 Nm)
8042, 10042, 10054 NA
250 - 350 lb-ft
(339 - 474 Nm)
85 - 95 lb-ft
(115 - 129 Nm)
30 - 35 lb-ft
(41 - 47 Nm)
Head Locknut Valve
300-400 lb-ft
(407-542 Nm)
550 - 650 lb-ft
(745 - 881 Nm)
30 - 35 lb-ft
(41 - 47 Nm)
Model Head Locknut Valves
10042, 10054 250 - 350 lb-ft
(339 - 474 Nm)
1650 - 1800 lb-ft
(2237 - 2440 Nm)
30 - 35 lb-ft
(41 - 47 Nm)
