Skytrak 8042 - Calibrations

Electrical System
9-42
31211015 6036, 6042, 8042, 10042, 10054
9.16.5 Calibrations
Menu Sub-Menu Description Access Level
Fork TIlt
Cal. Fork Tilt?
Yes: Enter, No: Esc
Allows the operator to calibrate the cabin
joystick’s fork tilt roller. Press Enter to continue or
ESC to exit from the menu.
Access Level 2, 3
Fork Tilt Roller
Fwd To Max
Knurl the fork tilt roller to +AR position and press
Enter key to confirm.
Fork Tilt Roller Center
Release the fork tilt roller to center position and
press Enter key to confirm.
Fork Tilt Roller
Rev To Max
Knurl the fork tilt roller to -AR position and press
Enter key to confirm.
Fork Tilt Roller Center
Release the fork tilt roller to center position to
and press Enter key to confirm.
Complete
The control system will display this message if
the procedure is successful. Press the ESC key to
exit from the menu.
Failed
The control system will display this message if
the procedure is failed. Press the ESC key to exit
from the menu.
