Skytrak 8042 - Electrical System Data; Engine Performance Specifications

General Information and Specifications
2-5
6036, 6042, 8042, 10042, 10054 31211015
2.2.3 Electrical System
2.2.4 Engine Performance Specifications
Note: No adjustment of the throttle is required. The engine Low Idle and High Idle are controlled by the engine ECM and cannot be
adjusted without Cummins programing tools.
Battery
Type, Rating 12 BCI, Negative (-) Ground, Maintenance Free
Quantity 1
Cold Cranking Amps 3.8 Liter - 950 CCA @ 0° F (-18° C)
Reserve Capacity 205 Minutes @ 80° F (27° C)
Group/Series Group 31 - 950
Alternator 12V, 135 Amps
Description 6036 & 6042
If Equipped for ULS
6036 & 6042
If Equipped for LS
6036 & 6042
If Equipped w/ 74hp (55kW)
Engine Make/Model Cummins Turbo QSF3.8 Cummins Turbo QSF3.8 Cummins Turbo QSF3.8
Displacement 232 in
3
(3,8 liters) 232 in
3
(3,8 liters) 232 in
3
(3,8 liters)
Low Idle (no load) 1000 rpm 1000 rpm 1000 rpm
High Idle (no load) 2500 rpm 2500 rpm 2500 rpm
Horsepower 85 hp (63 kW) @ 2500 rpm 85 hp (63 kW) @ 2500 rpm 74 hp (55 kW) @ 2500 rpm
Peak Torque 340 lb-ft (461 Nm) @ 1400 rpm 340 lb-ft (461 Nm) @ 1400 rpm 295 lb-ft (400 Nm) @ 1300 rpm
Fuel Delivery High Pressure Common Rail (HPCR) Fuel Injection
Air Cleaner Dry Type, Replaceable Primary and Safety Elements
Description 8042, 10042 & 10054
If Equipped for ULS
8042, 10042 & 10054
If Equipped for LS
8042, 10042 & 10054
If Equipped w/ 74hp (55kW)
Engine Make/Model Cummins Turbo QSF3.8 Cummins Turbo QSF3.8 Cummins Turbo QSF3.8
Displacement 232 in
3
(3,8 liters) 232 in
3
(3,8 liters) 232 in
3
(3,8 liters)
Low Idle 1000 rpm 1000 rpm 1000 rpm
High Idle 2500 rpm 2500 rpm 2500 rpm
Horsepower 110 hp (82 kW) @ 2500 rpm 110 hp (82 kW) @ 2500 rpm 74 hp (55 kW) @ 2500 rpm
Peak Torque 348 lb-ft (472 Nm) @ 1500 rpm 348 lb-ft (472 Nm) @ 1500 rpm 295 lb-ft (400 Nm) @ 1300 rpm
Fuel Delivery High Pressure Common Rail (HPCR) Fuel Injection
Air Cleaner Dry Type, Replaceable Primary and Safety Elements
