Stabil-TRAK™ System and Boom Interlock System
10-4
31211015 6036, 6042, 8042, 10042, 10054
10.2 BOOM EXTEND INTERLOCK SYSTEM
COMPONENT TERMINOLOGY (10054
ONLY)
To understand the safety, operation and maintenance
information presented in this section, it is necessary that the
operator/mechanic be familiar with the names and locations
of the major assemblies of the boom extend interlock system.
The following illustration identifies the components that are
referred to throughout this section.
BOOM EXTEND SENSOR
OUTRIGGER CYLINDER
PRESSURE SWITCH (2)
BOOM LOCKOUT
VALVE
