General Information and Specifications
2-28
31211015 6036, 6042, 8042, 10042, 10054
2.7.2 Metric Fastener Torque Chart (Continued)
Values for Zinc Yellow Chromate Fasteners (Ref 4150707)*
CLASS 10.9 METRIC (HEX HEAD) BOLTS,
CLASS 10 METRIC NUTS CLASS 12.9 SOCKET HEAD CAP SCREWS M3 - M5*
Size Pitch
Tensile
Stress Area
Clamp
Load
See
Note 4
Torque
(Dry or Loctite® 263
™
)
K=0.20
T o r q u e
(Lube or Loctite®
242
™
or 271
™
or
Vibra-TITE
™
111 or
140) K=0.18
T o r q u e
(Loctite® 262
™
or
Vibra-TITE
™
131)
K=0.15
Sq mm KN [N.m] [N.m] [N.m]
3 0.5 5.03 3.13
3.5 0.6 6.78 4.22
4 0.7 8.78 5.47
5 0.8 14.20 8.85
6 1 20.10 12.5
7 1 28.90 18.0 25 23 19
8 1.25 36.60 22.8 37 33 27
10 1.5 58.00 36.1 70 65 55
12 1.75 84.30 52.5 125 115 95
14 2 115 71.6 200 180 150
16 2 157 97.8 315 280 235
18 2.5 192 119.5 430 385 325
20 2.5 245 152.5 610 550 460
22 2.5 303 189.0 830 750 625
24 3 353 222.0 1065 960 800
27 3 459 286.0 1545 1390 1160
30 3.5 561 349.5 2095 1885 1575
33 3.5 694 432.5 2855 2570 2140
36 4 817 509.0 3665 3300 2750
42 4.5 1120 698.0 5865 5275 4395
NOTES: 1. THESE TORQUE VALUES DO NOT APPLY TO CADMIUM PLATED FASTENERS 5000059K
2. ALL TORQUE VALUES ARE STATIC TORQUE MEASURED PER STANDARD AUDIT METHODS TOLERANCE = ±10%
3. * ASSEMBLY USES HARDENED WASHER
4. CLAMP LOAD LISTED FOR SHCS IS SAME AS GRADE 8 OR CLASS 10.9 AND DOES NOT REPRESENT FULL STRENGTH CAPABILITY OF SHCS.
IF HIGHER LOAD IS REQUIRED, ADDITIONAL TESTING IS REQUIRED.
