LED 1, 2, 3, 4 (I/Q: Pin No. 2) for EX600-LAB1
The LED displays the status of Pin No.2 (Digital input) of each IO-Link port of the SI unit.
Pin function
LED status
Details
DI
(Digital input)
OFF
Input signal OFF
Orange ON
Input signal ON
: For details and countermeasures, refer to troubleshooting.
LED 1, 2, 3, 4 (P24: Pin No. 2) for EX600-LBB1
The LED displays the status of Pin No.2 (Power supply for output) of each IO-Link port of the SI unit.
Pin function
LED status
Details
P24
(Power supply for output)
OFF
Power supply for output OFF
Green ON
Power supply for output ON
Red ON
Short circuit detection (P24)
: For details and countermeasures, refer to troubleshooting.
All LEDs Common for EX600-LAB1 and EX600-LBB1
Pin function
LED status
Details
Condition of all pins
Red/green flashing
alternately
Internal memory error
: For details and countermeasures, refer to the troubleshooting section.
