M
ULTICAST
VLAN R
EGISTRATION
C
OMMANDS
4-257
The following shows information about the interfaces associated with
multicast groups assigned to the MVR VLAN:
Table 4-72 show mvr interface - display description
Field Description
Port Shows interfaces attached to the MVR.
Type Shows the MVR port type.
Status Shows the MVR status and interface status. MVR status for
source ports is “ACTIVE” if MVR is globally enabled on
the switch. MVR status for receiver ports is “ACTIVE” only
if there are subscribers receiving multicast traffic from one
of the MVR groups, or a multicast group has been statically
assigned to an interface.
Immediate Leave Shows if immediate leave is enabled or disabled.
Console#show mvr members
MVR Group IP Status Members
---------------- -------- -------
225.0.0.1 ACTIVE eth1/1(d), eth1/2(s)
225.0.0.2 INACTIVE None
225.0.0.3 INACTIVE None
225.0.0.4 INACTIVE None
225.0.0.5 INACTIVE None
225.0.0.6 INACTIVE None
225.0.0.7 INACTIVE None
225.0.0.8 INACTIVE None
225.0.0.9 INACTIVE None
225.0.0.10 INACTIVE None
Console#
Table 4-73 show mvr members - display description
Field Description
MVR Group IP Multicast groups assigned to the MVR VLAN.
Status Shows whether or not the there are active subscribers for
this multicast group. Note that this field will also display
“INACTIVE” if MVR is globally disabled.
Members Shows the interfaces with subscribers for multicast services
provided through the MVR VLAN. Also shows if an
interface has dynamically joined a multicast group (d), or if
a multicast group has been statically bound to the interface
(s).
