D717 User Manual Configuring the Function Keys
Example 3, Speed dialing
Besides using the Speed Dial page on the web interface to program speed dial numbers, you can also
put the functionality on the freely programmable function keys with LEDs on the phone or a connected
expansion module. In our example, key P2 of the function keys will be used to speed dial the number
9175550123.
1. On the phone's web interface, click on Function Keys in the menu on the left.
2. Click the Key Assignment tab, if necessary.
3. Under Context of P2, select "Active" or one of the configured identities from the drop-down list.
4. Under Type, select "Speed Dial" from the drop-down list.
5. In the Number text field, enter the phone number that you want to be able to speed dial. In our
example it is phone number 555-0123 in area code 917.
Type each phone number with any necessary area code and/or country code etc. without spaces,
hyphens, etc. Example: In conventional notation you might write the number as (917) 555-0123.
Type 9175550123 into the text field.
6. Select a display option from the drop-down menu of Short Label Mode. The default is "Icon and
text", i.e., an icon depicting the function on the key and the number or the short label text will be
displayed on the display. name or descriptive text.
7. Select a display option from the drop-down menu of Full Label Mode. The default is "Icon and
text", i.e., an icon depicting the function on the key and the number or the short label text will be
displayed on the display.
8. Optional: In the text fields of Short Label and Short Label, enter a name or descriptive text. In
our example, it is "Mary" and "Mary Pickford", respectively. If either one or both of the text fields
are empty, the label area will display the number.
9. Click on Apply and Save.
You can now speed dial the number 9175550123 by pressing the LED key adjacent to the label.
