SNR S2940-8G-v2 Switch Configuration Guide
DHCP Configuration
Command Explanation
Global Mode
ip dhcp relay share-vlan
<vlanid> sub-vlan <vlanlist>
no dhcp relay share-vlan
Create or delete share-vlan and it's sub-vlan.
34.4 DHCP Configuration Examples
Scenario 1:
Too save configuration efforts of network administrators and users, a company is using switch
as a DHCP server. The Admin VLAN IP address is 10.16.1.2/16. The local area network for the
company is divided into network A and B according to the office locations. The network configu-
rations for location A and B are shown below.
Pool A (network 10.16.1.0) Pool B (network 10.16.2.0)
Device IP address Device IP address
Default gateway 10.16.1.200 10.16.1.201 Default gateway 10.16.1.200 10.16.1.201
DNS server 10.16.1.202 DNS server 10.16.1.202
WINS server 10.16.1.209 WWW server 10.16.1.209
WINS node type H-node
Lease 3 days Lease 1day
In location A, a machine with MAC address 00-03-22-23-dc-ab is assigned with a fixed IP
address of 10.16.1.210 and named as 'management'.
Switch(config)#service dhcp
Switch(config)#interface vlan 1
Switch(Config-Vlan-1)#ip address 10.16.1.2 255.255.0.0
Switch(Config-Vlan-1)#exit
Switch(config)#ip dhcp pool A
Switch(dhcp-A-config)#network 10.16.1.0 24
Switch(dhcp-A-config)#lease 3
Switch(dhcp-A-config)#default-route 10.16.1.200 10.16.1.201
Switch(dhcp-A-config)#dns-server 10.16.1.202
Switch(dhcp-A-config)#netbios-name-server 10.16.1.209
Switch(dhcp-A-config)#netbios-node-type H-node
Switch(dhcp-A-config)#exit
Switch(config)#ip dhcp excluded-address 10.16.1.200 10.16.1.201
Switch(config)#ip dhcp pool B
Switch(dhcp-B-config)#network 10.16.2.0 24
Switch(dhcp-B-config)#lease 1
Switch(dhcp-B-config)#default-route 10.16.2.200 10.16.2.201
Switch(dhcp-B-config)#dns-server 10.16.2.202
Switch(dhcp-B-config)#option 72 ip 10.16.2.209
Switch(dhcp-config)#exit
Switch(config)#ip dhcp excluded-address 10.16.2.200 10.16.2.201
224
