SNR S2940-8G-v2 Switch Configuration Guide
802.1x Configuration
The access device will add the port into Guest VLAN if there is no supplicant getting authenticated
successfully in a certain stretch of time because of lacking exclusive authentication supplicant
system or the version of the supplicant system being too low.
Once the 802.1x feature is enabled and the Guest VLAN is configured properly, a port will be
added into Guest VLAN, just like Auto VLAN, if there is no response message from the supplicant
system after the device sends more authentication-triggering messages than the upper limit (EAP-
Request/Identity) from the port.
• The authentication server assigns an Auto VLAN, and then the port leaves Guest VLAN and
joins the assigned Auto VLAN. When the user becomes offline, the port will be allocated to
the specified Guest VLAN again.
• The authentication server assigns an Auto VLAN, and then the port leaves Guest VLAN and
joins the specified VLAN. When the user becomes offline, the port will be allocated to the
specified Guest VLAN again.
45.2 802.1x Configuration Task List
802.1x Configuration Task List:
1. Enable IEEE 802.1x function
2. Access management unit property configuration
(a) Configure port authentication status
(b) Configure access management method for the port: MAC-based or port-based
(c) Configure expanded 802.1x function
(d) Configure the max user number
3. User access devices related property configuration (optional)
1. Enable 802.1x function
Command Explanation
Global Mode
dot1x enable
no dot1x enable
Enables the 802.1x function in the switch
and ports; the no command disables the
802.1x function.
dot1x privateclient enable
no dot1x privateclient enable
Enables the switch force client software us-
ing private 802.1x authentication packet for-
mat. The no command will disable this func-
tion.
dot1x
user
free-resource
<prefix>
<mask>
no dot1x user free-resource
Sets free access network resource for
unauthorized dot1x user. The no command
close the resource.
dot1x unicast enable
no dot1x unicast enable
Enable the 802.1x unicast passthrough
function of switch; the no operation of this
command will disable this function.
316
