SNR S2940-8G-v2 Switch Configuration Guide
Switch management
port-
channel
Type interface port-channel
<port-channel-number> com-
mand under Global Mode.
Configure port-
channel related
settings such as
duplex mode, speed,
etc.
Use the exit com-
mand to return to
Global Mode.
VLAN Mode
Using the vlan <vlan-id> command under Global Mode can enter the corresponding VLAN Mode.
Under VLAN Mode the user can configure all member ports of the corresponding VLAN. Run the
exit command to exit the VLAN Mode to Global Mode.
DHCP Address Pool Mode
Type the ip dhcp pool <name> command under Global Mode will enter the DHCP Address Pool
Mode prompt Switch(Config-<name>-dhcp)#. DHCP address pool properties can be configured
under DHCP Address Pool Mode. Run the exit command to exit the DHCP Address Pool Mode
to Global Mode.
ACL Mode
ACL type Entry Operates Exit
Standard
IP ACL
Mode
Type ip access-list standard
command under Global Mode.
Configure parame-
ters for Standard IP
ACL Mode.
Use the exit com-
mand to return to
Global Mode.
Extended
IP ACL
Mode
Type ip access-list extended
command under Global Mode.
Configure parame-
ters for Extended IP
ACL Mode.
Use the exit com-
mand to return to
Global Mode.
1.2.2 Configuration Syntax
Switch provides various configuration commands. Although all the commands are different, they
all abide by the syntax for Switch configuration commands. The general commands format of
Switch is shown below:
cmdtxt <variable> {enum1 | ... | enumN } [option1 | ... | optionN]
Conventions:
cmdtxt indicates a command keyword;
<variable> indicates a variable parameter;
{ enum1 | ... | enumN } indicates a mandatory parameter that should be selected from the
parameter set enum1 enumN; and the square bracket ([ ]) in
textbf[option1 | … | optionN] indicate an optonal parameter. There may be combinations of < >,
{ } and [ ] in the command line, such as [<variable>], {enum1 <variable> | enum2}, [option1
[option2]], etc.
Here are examples for some actual configuration commands:
19
