SE7600A-US
1
Unit
Lower Power Output Higher Power Output
Revenue Grade Data, ANSI C12.1 Optional
2
Integrated AC, DC and Communication
Connection Unit
Yes
AC Disconnect Yes
Manual Inverter Bypass Switch Yes
DC Voltage Rapid Shutdown (PV and
Battery)
Yes, according to NEC 2014 and 2017 690.12
Auto-transformer thermal protection Yes
STANDARD COMPLIANCE
Safety UL1741,UL1741 SA, UL1699B, UL1998, CSA 22.2
Grid Connection Standards IEEE1547, Rule 21, Rule 14H
Emissions FCC part15 class B
INSTALLATION SPECIFICATIONS
AC Output (Loads/Grid) conduit size /
AWG range
1” / 14-6 AWG in/AWG
AC Output (Backup) conduit size / AWG
range
0.75-1” drill guides / 14-6 AWG in/AWG
AC Input (Auto-transformer) conduit size
/ AWG range
0.75-1 ” / 14-6 AWG in/AWG
DC Input (PV) conduit size / AWG range 0.75 ” / 14-8 AWG in/AWG
DC Input (Battery) conduit size / AWG
range
0.75” / 12-10 AWG in/AWG
Dimensions with Connection Unit
(HxWxD)
37 x 12.5 x 7.2 / 940 x 315 x 184 in / mm
Weight with Connection Unit 58.5 / 26.5 lb / kg
Cooling Natural convection and internal fan (user replaceable)
Noise < 50 dBA
Min - Max Operating Temperature -13 to +140 / -25 to +60 °F / °C
Protection Rating NEMA 3R
1
These specifications apply to inverters with part numbers SE7600A-USS2XXXXX and connection unit model number
BCU-1PH-USS.
2
Revenue grade inverter P/N: SE7600A-USS20NNM2
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.3
112
StorEdge Inverter
