BU
S
RO
UTING
To route channels to the Record and Mix busses, press the REC and/or MIX switch to the right of the
c
hannel pan pot.
Use the eight numbered switches immediately underneath the channel meters (shown above right) to
route to the track busses. By default, signals are sent post-fader. To source the send pre-fader or post
pan-control, press the PRE or PAN switches beneath the track bus selection switches.
PANNING
The pan pot towards the bottom of the channel strip is used to adjust the stereo position of signals being sent to the
Record and Mix busses, as well as to the Track busses when they are functioning in stereo.
LEVEL, CUTS AND SOLOS
The channel fader controls the channel send to the Rec and Mix busses, as well as any other sends which are operating
post-fader. Use the CUT and SOLO switches below the digital display to mute or solo the signal assigned to the fader.
AWS 916-924 Tutorial
Page 2a-4 AWS δelta Owner’s Manual
