Technical Specifications
62
Appendix B - Technical Specifications
Physical
Build area 3Z Pro
Build area 3Z Studio
Build area 3Z Max
X: 6” (15 cm)
X: 6” (15 cm)
X: 6” (15 cm)
Y: 6”(15 cm)
Y: 6”(15 cm)
Y: 6”(15 cm)
Z: 4” (10 cm)
Z: 2” (5 cm)
Z: 4” (10 cm)
Dimensions (closed) W: 22” (56 cm) D: 19.5” (50 cm) H: 16.5” (42 cm)
Dimensions (opened) W: 36” (92 cm) D: 19.5” (50 cm) H: 35” (89 cm)
Dimensions (carton) W: 26” (66 cm) D: 24” ( cm) H: 21” (54 cm)
Dimensions (palletized) W: 32” (81 cm ) D: 32” (81 cm) H: 47” (120 cm)
Unit weight 75 lb. (34 Kg)
Palletized ship weight 165 lb. (75 Kg)
Physical: Unit Only
Room Temperature
16C (60F) to 27C (80 F)
Humidity 40% to 60%
Rated Voltage / Current 100 - 240 VAC / 5 Amps
Fuse 5 Amp Slow Blow (T) 250V
Certifications CE Certified TUV FCC Class A
Unattended Operation 72 hours max
Reservoirs
Level Accuracy +/- 5%
Capacity (max) 5 crayons = 150 ml (liquid)
Refill On prompt During operation
Physical: Vacuums
Rated Voltage / Current 120V Model: 120 VAC 14 Amps
230V Model: 230 VAC 8 Amps
Model Characteristics
X, Y, Z Accuracy
 0.001 inch per inch
Z-axis layer 3Z Pro
Z-axis layer 3Z Studio
Z-axis layer 3Z Max
.00025 inch (.00635 mm) to .003 inch (.0762 mm)
.00025 inch (.00635 mm) to .001 inch (.0254 mm)
.001 inch (.0254mm) to .002 inch (.0508mm)
Dimensional .001 inch per inch (X, Y, and Z axes)
Surface finish 32 to 63 micro-inches (RMS)
Minimum feature size .010 inch (.254 mm)
Droplet size .003 inch (.076 mm)
Carriage calibration Automatic before each build
