3-4
BVW-55
MAINTENANCE MODE
M0 : TAPE MAINTENANCE
M2 : ERROR LOGGER
M3 : OTHERS
M4 : SETUP MAINTENANCE
*


Activating the Maintenance Mode
(1) Press the 8 S201 switch (on the SY-272 board).
(2) The mode screen in the maintenance mode is superimposed on the LCD monitor.
In a 1 sub LCD, “M0-TAPE MAINTEN” is displayed.
LCD Monitor Sub LCD
Activating the Maintenance Mode from Control Panel
The maintenance mode can be activated by the operation below when 9S202-2 switch (on the SY-272
board) is set to ON (upper).
(1) Press the 2 MENU button once.
(Execute the setup menu mode from the operation mode.)
(2) Press the 3 SET button while pressing the 4 CTL/TC/U-BIT button.
(Execute the maintenance mode from the setup menu mode.)
(3) The mode screen in the maintenance mode is displayed on the LCD monitor.
Terminating the Maintenance Mode
(1) Press the 2 MENU button several times to display the mode screen on the LCD monitor.
The selected mode No. and title are displayed in a sub LCD.
(2) Press the 2 MENU button again to terminate the maintenance mode.
3-1. Overview of Maintenance Mode
M0 -TAPE MAINTEN
