4-67
CCD-TR618/TR618E/TR718E/TR728E/TR818/TRV49/TRV49E/TRV58/
TRV58E/TRV59E/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E
VF-141 BOARD
2 IC4501 ws

3 IC4501 wf

4 IC4501 rh
7.2Vp-p
0.5Vp-p
5 IC4501 rj
0.43Vp-p
0.50Vp-p
6 IC4501 rk
10.86 MHz
1.3Vp-p
7 IC4502 wh
1 IC4501 w;
7.2Vp-p
2H
2H
2H
2H
2H
2H
7.2Vp-p
LB-062 BOARD
1 IC4601 4
4.6Vp-p
H
CF-077 BOARD
25.346 kHz
3.0Vp-p
1 IC001 2
WAVEFORMS
VF-141, LB-062, CF-077
