Sony CCD-TR618 - Waveforms

4-66
CCD-TR618/TR618E/TR718E/TR728E/TR818/TRV49/TRV49E/TRV58/
TRV58E/TRV59E/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E
WAVEFORMS
CD-281/286, MI-040/041, PD-131, VF-129
4-3. WAVEFORMS
CD-281/286 BOARD
REC
2 IC191 3,4

3 IC191 7

4 IC191 qs“ 

0.6Vp-p
H
4.6Vp-p
105 nsec
5 IC191 qd,qf¢
105 nsec
6.8Vp-p
H
0.6Vp-p
6 Q191 E

1 IC191 1,2
6.8Vp-p
H
6.8Vp-p
H
MI-040/041 BOARD
REC/PB
2 IC3901 ws
IR ON
3 IC3901 ra
IR ON
1 IC3901 7
IR ON
0.2Vp-p
3.5795 MHz
0.9Vp-p
0.5 µsec/div
0.6Vp-p
H
PD-131 BOARD
2 IC5501 rj
1 IC5501 rk
0.5Vp-p
0.5Vp-p
2.8Vp-p
3 IC5501 rh

0.5Vp-p
4 IC5501 w;

2H
2H
2H
3.0Vp-p
5 IC5501 ws

3.0Vp-p
7 IC5502 1

6 IC5501 wf
H
3.0Vp-p
3.0Vp-p
8 IC5502 wh
6 MHz
H
H
H
VF-129 BOARD
REC/PB
2 IC901 3

3 IC901 7

4 IC901 qa
1.1Vp-p
16.7 msec
0.9Vp-p
H
5 IC901 qd
H
1.1Vp-p
H
2.4Vp-p
6 IC901 qh
1 IC901 1,5
2.0Vp-p
16.7 msec
2.0Vp-p
16.7 msec
