Sony CCD-TR618 - Lens Section; Board

2-11
2-10.LENS SECTION
2-11.VC-251 BOARD
VC-251
3 Screw
(M2
× 3),
lock ace, p2
1 FP-259 flexible board (14P)
2 Flexible board
(from lens block)(24P)
4 Two screws
(M2
× 3),
lock ace, p2
5 Claw
6
1
Two tapping
screws (B2
× 5)
2 Lens fram
e
3 Lens section
VC-251
1 Two screws
(M2 × 3),
lock ace, p2
5 Screw
(M2 × 3),
lock ace, p
2
7 VC-251 board
4 FP-257
flexible board
3 Two screws
(M2 × 3),
lock ace, p2
2 MD frame B
6 Control switch block
(FK-1000) (12P)
