Sony CCD-TR618 - Auto White Balance Adjustment

CCD-TR618/TR618E/TR718E/TR728E/TR818/TRV49/TRV49E/TRV58/
TRV58E/TRV59E/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E
— 39 —
Page
5-21
Type S
Type M
: Added portion.
9. Auto White Balance Adjustment
Adjust to the proper auto white balance output data.
If it is not correct, auto white balance and color reproducibility
will be poor.
Subject Clear chart
(Color reproduction adjustment frame)
Filter Filter C14 for color temperature
correction
Measurement Point Display data of page 1 (Note4)
Measuring Instrument Adjustment remote commander
Adjustment Page F
Adjustment Address 42, 43
Specified Value 1/6 CCD NTSC model:
R ratio: 2AC0 to 2B40
B ratio: 5E20 to 5EE0
1/6 CCD PAL model:
R ratio: 2B40 to 2BC0
B ratio: 61A0 to 6260
1/4 CCD NTSC model:
R ratio: 2D40 to 2DC0
B ratio: 5D20 to 5DE0
1/4 CCD PAL model:
R ratio: 2B40 to 2BC0
B ratio: 5D20 to 5DE0
Adjusting method:
Order Page Address Data Procedure
1 Place the C14 filter for color
temperature correction on the lens.
2 0 01 01 Set the data.
3 F B8 Write down the data.
4 F B8 Set the following data, and press
PAUSE button.
2B: 1/6 CCD NTSC model
2B: 1/6 CCD PAL model
2D: 1/4 CCD NTSC model
2B: 1/4 CCD PAL model
5 F B9 Write down the data.
6 F B9 Set the following data, and press
PAUSE button.
00: 1/6 CCD NTSC model
80: 1/6 CCD PAL model
80: 1/4 CCD NTSC model
80: 1/4 CCD PAL model
7 F BA Write down the data.
8 F BA Set the following data, and press
PAUSE button.
5E: 1/6 CCD NTSC model
62: 1/6 CCD PAL model
5D: 1/4 CCD NTSC model
5D: 1/4 CCD PAL model
9 F BB Write down the data.
Specified Value 1/6 CCD NTSC model:
R ratio: 2AC0 to 2B40
B ratio: 5E20 to 5EE0
1/6 CCD PAL model:
R ratio: 2B40 to 2BC0
B ratio: 61A0 to 6260
1/4 CCD NTSC model (CCD type S):
R ratio: 2D40 to 2DC0
B ratio: 5D20 to 5DE0
1/4 CCD NTSC model (CCD type M):
R ratio: 2A40 to 2AC0
B ratio: 6120 to 61E0
1/4 CCD PAL model:
R ratio: 2B40 to 2BC0
B ratio: 5D20 to 5DE0
Adjusting method:
Order Page Address Data Procedure
4 F B8 Set the following data, and press
PAUSE button.
2B: 1/6 CCD NTSC model
2B: 1/6 CCD PAL model
2D: 1/4 CCD NTSC model
(CCD type S)
2A: 1/4 CCD NTSC model
(CCD type M)
2B: 1/4 CCD PAL model
8 F BA Set the following data, and press
PAUSE button.
5E: 1/6 CCD NTSC model
62: 1/6 CCD PAL model
5D: 1/4 CCD NTSC model
(CCD type S)
61: 1/4 CCD NTSC model
(CCD type M)
5D: 1/4 CCD PAL model
