3-1-6. Output Level and Impedance
Video output
Stereo minijack,
1Vp-p, 75Ω, unbalanced, sync negative
S video output
4-pin mini DIN
Luminance signal:
1Vp-p, 75Ω, unbalanced, sync negative
Chrominance signal:
0.286Vp-p, 75Ω, unbalanced (NTSC)
0.300Vp-p, 75Ω, unbalanced (PAL)
Audio output
Stereo minijack:
–7.5dBs, (at load impedance 47kΩ), impedance less than
2.2kΩ
3-1-7. Recording Mode (Standard 8/Hi8) switching
The record mode (Standard 8/Hi8) of this unit switches as shown in
the following table. The playback mode (Standard 8/Hi8) switches
automatically according to the recording mode of the tape played
back.
Tape Used Recording Mode
ME Hi8
Hi8 MP
MP Standard 8
