Sony CCD-TR618 - Electrical Parts List

CCD-TR618/TR618E/TR718E/TR728E/TR818/TRV49/TRV49E/TRV58/
TRV58E/TRV59E/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E
— 41 —
6-2. ELECTRICAL PARTS LIST
Page
6-11
Type S
Type M
: Added portion.
CD-286 BOARD, COMPLETE
***********************
(IC191 is not included in this mounted board)
< IC >
IC191 A-7031-040-A CCD BLOCK ASSY (TR618/TRV49/TRV58)
IC191 A-7031-043-A CCD BLOCK ASSY
(TR618E/TR718E/TR728E/TRV49E/TRV58E/TRV59E)
IC191 A-7031-049-A CCD BLOCK ASSY (TRV78E/TRV98E)
IC191 A-7031-207-A CCD BLOCK ASSY
(TR818/TRV68/TRV78/TRV88/TRV98)
IC191 A-7031-301-A CCD BLOCK ASSY
(TRV68/TRV78/TRV88/TRV98)
CD-286 BOARD, COMPLETE
***********************
(IC191 is not included in this mounted board)
< IC >
IC191 A-7031-040-A CCD BLOCK ASSY (TR618/TRV49/TRV58)
IC191 A-7031-043-A CCD BLOCK ASSY
(TR618E/TR718E/TR728E/TRV49E/TRV58E/TRV59E)
IC191 A-7031-049-A CCD BLOCK ASSY (TRV78E/TRV98E)
IC191 A-7031-207-A CCD BLOCK ASSY
(TR818/TRV68/TRV78/TRV88/TRV98)
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Type M
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7096-402-A VC-251 BOARD, COMPLETE (SERVICE)(TR618)
*************************************
A-7096-403-A VC-251 BOARD, COMPLETE (SERVICE)(TR818)
*************************************
A-7096-404-A VC-251 BOARD, COMPLETE (SERVICE)
(TR618E/TR718E/TR728E)
*************************************
A-7096-815-A VC-251 BOARD, COMPLETE (SERVICE)
(TRV68/TRV78/TRV88/TRV98)
*************************************
A-7096-406-A VC-251 BOARD, COMPLETE (SERVICE)
(TRV78E/TRV98E)
*************************************
A-7096-409-A VC-251 BOARD, COMPLETE (SERVICE)
(TRV49/TRV58)
*************************************
A-7096-456-A VC-251 BOARD, COMPLETE (SERVICE)
(TRV49E/TRV58E/TRV59E)
*************************************
(Ref.No.;10000 Series)
< CAPACITOR >
C001 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C002 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C003 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C004 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C008 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C009 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C010 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C011 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C012 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C013 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C014 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C015 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
C016 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C018 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
C019 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C020 1-117-808-91 CERAMIC CHIP 10uF 10% 10V
C021 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C022 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C023 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C024 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C025 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C026 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
C027 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C028 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C029 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C030 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
C031 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C032 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
C033 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C034 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
C035 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C036 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C037 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C038 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C039 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C040 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C041 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C042 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C043 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C045 1-119-749-11 TANTAL. CHIP 33uF 20% 4V
C046 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C047 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(TR818/TRV49/TRV49E/TRV58/TRV58E/TRV59E/
TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
C048 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
C049 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
