11. Angular Velocity Sensor Sensitivity Adjustment
(CCD-TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/
TRV98E)
Precautions on the Parts Replacement
There are two types of repair parts.
Type A: ENC03JA
Type B: ENC03JB
Replace the broken sensor with a same type sensor. If replace with
other type parts, the image will vibrate up and down or left and
right during hand-shake correction operations. After replacing, re-
adjust according to the adjusting method after replacement.
Precautions on Angular Velocity Sensor
The sensor incorporates a precision oscillator. Handle it with care
as if it dropped, the balance of the oscillator will be disrupted and
operations will not be performed properly.
Subject Arbitrary
Measurement Point Display data of page 1 (Note1)
Measuring Instrument Adjustment remote commander
Adjustment Page F
Adjustment Address 5E, 5F
Specified Value 2700 to 5100
Note1: Displayed data of the adjustment remote commander.
1 : XX : XX
Display data
Note2: MI-040 board: CCD-TR818
MI-041 board: CCD-TRV68/TRV78/TRV78E/TRV88/TRV98/
TRV98E
Switch setting:
1) STEADY SHOT (Menu display) ...................................... ON
2) ZOOM.......................................................................... Center
Adjusting method:
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 F 5E Set the following data, and press
PAUSE button.
5A (NTSC), 74 (PAL)
3 F 5F Set the following data, and press
PAUSE button.
57 (NTSC), 5D (PAL)
Pitch sensor check
(MI-040/041 board SE751)
4 0 03 11 Set the data.
5 1 Check that the display data (Note1)
satisfies the specified value.
Yaw sensor check
(MI-040/041 board SE752)
6 0 03 12 Set the data.
7 1 Check that the display data (Note1)
satisfies the specified value.
Processing after Completing Adjustments
Order Page
Address
Data Procedure
1 0 01 00 Set the data.
2 0 03 00 Set the data.
3 Move the camcorder, and check
that the steady shot operations
have been performed normally
To Next Page
