6-11
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
HK : Hong Kong model
KR : Korea model
JE : Tourist model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
AUS : Australian model
CN : Chinese model
BR : Brazilian model
AR : Argentina model
A-7074-658-A CD-286 BOARD, COMPLETE
(TR618/TR618E/TR718E/TR728E)
**************************************
A-7074-662-A CD-286 BOARD, COMPLETE (TR818)
******************************
A-7074-666-A CD-281 BOARD, COMPLETE
(TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
**************************************
A-7074-698-A CD-281 BOARD, COMPLETE
(TRV49/TRV49E/TRV58/TRV58E/TRV59E)
**************************************
(Ref.No.;1000 Series)
(IC191 is not included in this mounted board)
< CAPACITOR >
C191 1-126-395-11 ELECT 22uF 20% 16V
C195 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C196 1-128-994-21 ELECT CHIP 47uF 20% 10V
< CONNECTOR >
CN191 1-766-344-21 CONNECTOR, FFC/FPC 14P
< IC >
IC191 A-7031-040-A CCD BLOCK ASSY (TR618/TRV49/TRV58)
IC191 A-7031-043-A CCD BLOCK ASSY
(TR618E/TR718E/TR728E/TRV49E/TRV58E/TRV59E)
IC191 A-7031-049-A CCD BLOCK ASSY (TRV78E/TRV98E)
IC191 A-7031-207-A CCD BLOCK ASSY
(TR818/TRV68/TRV78/TRV88/TRV98)
< COIL >
L191 1-469-528-91 INDUCTOR 100uH
< TRANSISTOR >
Q191 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R191 1-216-797-11 METAL CHIP 10 5% 1/16W
R192 1-216-864-91 SHORT 0
R193 1-216-833-11 METAL CHIP 10K 5% 1/16W
R195 1-216-864-91 SHORT 0
R198 1-216-809-11 METAL CHIP 100 5% 1/16W
(TR618/TR618E/TR718E/TR728E/TRV49/
TRV49E/TRV58/TRV58E/TRV59E)
R198 1-216-864-91 SHORT 0
(TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
************************************************************
A-7074-663-A CF-077 BOARD, COMPLETE
(TR618/TR618E/TR718E/TR728E/TR818)
**************************************
(Ref.No.;1000 Series)
< BATTERY >
BT001 1-756-146-11 BATTERY, LITHIUM (SECONDARY)
< BUZZER >
BZ001 1-529-107-11 BUZZER, PIEZOELECTRIC
< CAPACITOR >
C001 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-794-050-21 CONNECTOR, FFC/FPC (ZIF) 26P
< IC >
IC001 8-759-573-02 IC BU9735K-E2
< RESISTOR >
R005 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R006 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R010 1-216-855-11 METAL CHIP 680K 5% 1/16W
R011 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R013 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R014 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R015 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R016 1-216-834-11 METAL CHIP 12K 5% 1/16W
R017 1-216-840-11 METAL CHIP 39K 5% 1/16W
R018 1-216-838-11 METAL CHIP 27K 5% 1/16W
R023 1-216-835-11 METAL CHIP 15K 5% 1/16W
< SWITCH >
S001 1-771-138-82 SWITCH, KEY BOARD (RESET)
S002 1-771-138-82 SWITCH, KEY BOARD (MENU)
S003 1-771-138-82 SWITCH, KEY BOARD (TIME)
S004 1-771-138-82 SWITCH, KEY BOARD (EXPOSURE)
S005 1-771-138-82 SWITCH, KEY BOARD (DATE)
Be sure to read “Precautions upon replacing CCD imager”
on page 4-8 when changing the CCD imager.
CD-286 CD-281 CF-077
