VC-251 BOARD
H
es IC221 wfƒ 
REC/PB
IR ON
0.52Vp-p
ed IC221 ws»
REC/PB
R2.4Vp-p
P2.1Vp-p
H
eg IC402 rj
REC/PB
ef IC402 1
REC/PB
1.6Vp-p
20.0 MHz
2.8Vp-p
25 Hz
ej IC451 ws
REC/PB
ek IC451 qh
REC/PB
el IC451 wg
REC/PB
r; IC451 wk
REC/PB
eh IC451 tj,tl,ya»
REC/PB
1.3Vp-p
5.6 msec
2.8Vp-p
2.8Vp-p
50mVp-p
80mVp-p
30 Hz
5.6 msec
13 µsec
13 µsec
rs IC503 td
REC/PB
ra IC503 r;
REC/PB
2.9Vp-p
20.0 MHz
3.0Vp-p
32.768 kHz
rf IC001 yf¢ 
REC/PB
rd IC001 tk
REC/PB
0.75Vp-p
2.2 µsec
0.75Vp-p
2.2 µsec
WAVEFORMS
VC-251
