5-3
Board
replacement
z
zz
zz
zz
zz
zz
zz
zz
zz z
zzz
zzz
zzz
zzz
z
z
z
z
z
z
zz z
zz z
zz z
zz z
zz z
zz z
zz
zz
z
z
z
z
z
z
z
zz
zz
zz
z
z
VC-251 board (COMPLETE) MI-040/041 board (COMPLETE) *7 PD-131 board (COMPLETE) *4 VF-129 board (COMPLETE) *3
VF-141 board (COMPLETE) *2 VC-251 board IC401 EEPROM
*1: When replacing the drum assy. or mechanism deck,
reset the data of page: 2, address: A2 to A4 to “00”.
(Refer to “Record of Use check” of “5-4. SERVICE
MODE”)
*2: Color EVF model (CCD-TR818)
*3: B/W EVF model (CCD-TR618/TR618E/TR718E/
TR728E/TRV49/TRV49E/TRV58/TRV58E/TRV59E/
TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
*4: TRV model: (CCD-TRV49/TRV49E/TRV58/TRV58E/
TRV59E/TRV68/TRV78/TRV78E/TRV88/TRV98/
TRV98E)
*5: LASER LINK model (CCD-TRV98)
*6: Steady shot model (CCD-TR818/TRV68/TRV78/
TRV78E/TRV88/TRV98/TRV98E)
*7: MI-040 board: TR model
MI-041 board: TRV model
*8: When replacing the video light, reset the data of page:
2, address: E0 to E2 to “00”. (Except for CCD-TR818)
Table. 5-1-1(2).
Adjustment
Section
Initialization of D,
E, F, 7 page data
Camera
Color EVF *2
B/W EVF *3
LCD *4
Servo
Video
IR *5
Audio
Mechanism
Adjustment
Initialization of D, E, F, 7 page data
Modification of D, E, F, 7 page data
Lens type input
HALL adj.
Flange back adj.
Color reproduction adj.
AWB & LV standard data input
Auto white balance adj.
Angular velocity sensor sens. adj. *6
RGB AMP adj.
Contrast adj.
Backlight consumption current adj.
White balance adj.
Centering adj.
Focus adj.
Aberration adj.
Horizontal amplitude adj.
Vertical amplitude adj.
Brightness adj.
VCO adj.
RGB AMP adj.
Contrast adj.
COM-AMP adj.
V-COM adj.
White balance adj.
CAP FG offset adj.
Switching position adj.
28MHz origin oscillation adj.
AFC fo adj.
Filter fo adj.
Y OUT level adj.
C OUT level adj.
REC Y current adj.
REC C/AFM current adj.
IR video carrier frequency adj.
IR video deviation adj.
IR audio deviation adj.
1.5MHz deviation adj.
BPF fo adj.
Tape path adj.
