— 11 —
E
E
E
E
Block
Function
61
61
62
62
Detailed
Code
00
10
00
01
Symptom/State
Difficult to adjust focus
(Cannot initialize focus.)
Zoom operations fault
(Cannot initialize zoom lens.)
Handshake correction function does not
work well. (With pitch angular velocity
sensor output stopped.)
Handshake correction function does not
work well. (With yaw angular velocity
sensor output stopped.)
Self-diagnosis Code
Repaired by:
Correction
Inspect the lens block focus reset sensor (Pin qs of CN301 of VC-
251 board) when focusing is performed when the control dial is
rotated in the focus manual mode and the focus motor drive circuit
(IC301 of VC-251 board) when the focusing is not performed.
Inspect the lens block zoom reset sensor (Pin qf of CN301 of VC-
251 board) when zooming is performed when the zoom lens is
operated and the zoom motor drive circuit (IC301 of VC-251 board)
when zooming is not performed.
Inspect pitch angular velocity sensor (SE751 of MI-040/041
board) peripheral circuits. *1
Inspect yaw angular velocity sensor (SE752 of MI-040/041
board) peripheral circuits. *1
*1: STEADY SHOT model (CCD-TR818/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
