6-15
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
C5531 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C5603 1-164-657-11 CERAMIC CHIP 0.015uF 10% 50V
C5604 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5605 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
0 C5606 1-131-959-91 CERAMIC CHIP 12PF 10% 3KV
C5607 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
< CONNECTOR >
CN5501 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
* CN5502 1-573-984-11 CONNECTOR, BOARD TO BOARD 10P
CN5601 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN5701 1-794-998-21 PIN, CONNECTOR 20P
CN5702 1-573-346-21 CONNECTOR, FFC/FPC 6P
< DIODE >
D5502 8-713-102-80 DIODE 1T369-01-T8A
D5503 8-719-073-01 DIODE MA111-(K8).S0
D5503 8-719-988-61 DIODE 1SS355TE-17
D5601 8-719-073-01 DIODE MA111-(K8).S0
D5601 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB003 1-414-760-21 FERRITE 0UH
FB5501 1-414-760-21 FERRITE 0UH
FB5501 1-414-760-21 FERRITE 0UH
FB5501 1-414-760-21 FERRITE 0UH
FB5501 1-500-329-21 FERRITE 0UH
FB5502 1-414-760-21 FERRITE 0UH
FB5502 1-414-760-21 FERRITE 0UH
FB5502 1-414-760-21 FERRITE 0UH
FB5502 1-500-329-21 FERRITE 0UH
< IC >
IC5501 8-759-660-92 IC RB5P003AM1
IC5502 8-759-714-77 IC LZ9FF474
IC5601 8-759-564-49 IC TC7W53FU(TE12R)
IC5602 8-759-075-70 IC TA75S393F-TE85R
< COIL >
L001 1-419-354-21 INDUCTOR 22uH
L5501 1-469-525-91 INDUCTOR 10uH
L5502 1-469-525-91 INDUCTOR 10uH
L5503 1-412-949-21 INDUCTOR 6.8uH
(TRV88/TRV98/TRV98E)
L5503 1-412-956-21 INDUCTOR 27uH
(TRV49/TRV49E/TRV58/TRV58E/
TRV59E/TRV68/TRV78/TRV78E)
L5601 1-419-387-11 INDUCTOR 100uH
< TRANSISTOR >
Q5502 8-729-041-23 TRANSISTOR NDS356AP
Q5503 8-729-054-48 TRANSISTOR N1B04FE-Y/GR(TPLR3)
Q5504 8-729-054-48 TRANSISTOR N1B04FE-Y/GR(TPLR3)
Q5505 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q5601 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q5602 8-729-039-43 TRANSISTOR FP216-TL
< RESISTOR >
R5501 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5503 1-218-893-11 METAL CHIP 82K 0.5% 1/16W
(TRV88/TRV98/TRV98E)
R5503 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
(TRV49/TRV49E/TRV58/TRV58E/
TRV59E/TRV68/TRV78/TRV78E)
R5505 1-216-835-11 METAL CHIP 15K 5% 1/16W
R5506 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R5507 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5508 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5509 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5510 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5511 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5512 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5513 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5515 1-216-864-91 SHORT 0
R5516 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5519 1-216-864-91 SHORT 0
R5521 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5522 1-216-821-11 METAL CHIP 1K 5% 1/16W
(TRV49/TRV49E/TRV58/TRV58E/
TRV59E/TRV68/TRV78/TRV78E)
R5522 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(TRV88)
R5522 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
(TRV98/TRV98E)
R5523 1-216-864-91 SHORT 0
R5531 1-216-848-11 METAL CHIP 180K 5% 1/16W
R5532 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5533 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5534 1-216-864-91 SHORT 0
R5535 1-216-864-91 SHORT 0
R5601 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R5602 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5603 1-216-834-11 METAL CHIP 12K 5% 1/16W
R5604 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R5606 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5607 1-216-817-11 METAL CHIP 470 5% 1/16W
R5610 1-216-864-91 SHORT 0
R5702 1-216-833-11 METAL CHIP 10K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB5501 1-234-372-21 RES, NETWORK 100X4 (1005)
RB5502 1-239-698-11 RESISTOR, NETWORK 10K
RB5503 1-239-661-81 RESISTOR, NETWORK 1M
RB5601 1-239-698-11 RESISTOR, NETWORK 10K
(TRV49/TRV49E/TRV58/TRV58E/
TRV59E/TRV68/TRV78/TRV78E)
RB5601 1-239-701-81 RESISTOR, NETWORK 18K
(TRV88/TRV98/TRV98E)
< TRANSFORMER >
0 T5601 1-435-227-11 TRANSFORMER, INVERTER
************************************************************
PD-131
