6-19
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< CONNECTOR >
* CN001 1-764-177-11 PIN, CONNECTOR (SMD)(1.5MM) 7P
CN101 1-766-346-21 CONNECTOR, FFC/FPC 16P
CN271 1-779-331-11 CONNECTOR, FFC/FPC 14P
CN301 1-750-360-21 CONNECTOR, FFC/FPC (ZIF) 24P
CN701 1-794-998-21 PIN, CONNECTOR 20P
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
CN702 1-766-350-21 CONNECTOR, FFC/FPC 20P
CN703 1-766-354-21 CONNECTOR, FFC/FPC 24P
CN704 1-766-644-21 CONNECTOR, FFC/FPC 8P
CN706 1-766-340-21 CONNECTOR, FFC/FPC 10P
CN707 1-766-342-21 CONNECTOR, FFC/FPC 12P
CN708 1-779-334-11 CONNECTOR, FFC/FPC 20P (TR818)
CN709 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN710 1-750-076-21 CONNECTOR, FFC/FPC 12P
CN711 1-764-704-21 CONNECTOR, FFC/FPC (LIF) 5P
CN712 1-766-345-21 CONNECTOR, FFC/FPC 15P
CN713 1-774-711-41 CONNECTOR, BOARD TO BOARD 20P
* CN715 1-778-283-11 CONNECTOR, FFC/FPC 4P (EXCEPT TR818)
< DIODE >
D001 8-719-421-27 DIODE MA728-(K8).S0
D002 8-719-062-16 DIODE 01ZA8.2(TPL3)
D004 8-719-073-03 DIODE MA8082-(K8).S0
D005 8-719-078-02 DIODE 1SS357(T3SONY1)
D006 8-719-081-19 DIODE 1SS383(T5RSONY1)
D007 8-719-081-19 DIODE 1SS383(T5RSONY1)
D010 8-719-078-02 DIODE 1SS357(T3SONY1)
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
D151 8-719-081-25 DIODE JDV3C11(TPH3)
D152 8-719-081-25 DIODE JDV3C11(TPH3)
D271 8-719-073-01 DIODE MA111-(K8).S0
(TR618/TR618E/TR718E/TR728E/TRV49/
TRV49E/TRV58/TRV58E/TRV59E)
D272 8-719-082-63 DIODE 1SV329(TPL3)
D301 8-719-073-01 DIODE MA111-(K8).S0
D501 8-719-421-67 DIODE MA132WK-(K8).SO
D503 8-719-421-27 DIODE MA728-(K8).S0
D504 8-719-073-01 DIODE MA111-(K8).S0
D702 8-719-062-16 DIODE 01ZA8.2(TPL3)
< PIN CONNECTOR >
ET101 1-815-032-21 PIN, CONNECTOR (CASE, SHIELD)
ET102 1-815-032-21 PIN, CONNECTOR (CASE, SHIELD)
< FUSE >
0 F001 1-576-406-21 FUSE, MICRO (1.4A) (1608)
0 F002 1-576-406-21 FUSE, MICRO (1.4A) (1608)
0 F003 1-576-406-21 FUSE, MICRO (1.4A) (1608)
0 F004 1-576-406-21 FUSE, MICRO (1.4A) (1608)
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
< FERRITE BEAD >
FB001 1-414-760-21 FERRITE 0UH
FB003 1-414-760-21 FERRITE 0UH
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
FB101 1-414-228-11 FERRITE 0UH
FB102 1-414-228-11 FERRITE 0UH
FB152 1-414-760-21 FERRITE 0UH
FB153 1-414-760-21 FERRITE 0UH
FB154 1-414-760-21 FERRITE 0UH
FB221 1-414-760-21 FERRITE 0UH
FB271 1-414-760-21 FERRITE 0UH
(TR618/TR618E/TR718E/TR728E/TRV49/
TRV49E/TRV58/TRV58E/TRV59E)
FB273 1-500-284-21 FERRITE 0UH
FB274 1-500-284-21 FERRITE 0UH
FB275 1-414-760-21 FERRITE 0UH
FB276 1-500-284-21 FERRITE 0UH
FB601 1-414-760-21 FERRITE 0UH
< IC >
IC001 8-752-090-20 IC CXA3057R-T6
IC101 8-752-093-69 IC CXA3265R-T4
IC151 8-759-670-78 IC HG75C012SFL
IC153 8-759-714-10 IC BU3095-01FV-E2
IC221 8-759-599-37 IC AN2225FHQ-EB
IC271 8-752-386-72 IC CXD2444R-T4
IC272 8-759-699-92 IC AD80013AJSTRL
IC301 8-759-637-96 IC MPC17A135DTAEL
IC302 8-759-681-42 IC NJM12902V(TE2)
IC351 8-752-093-74 IC CXA3285R-T6
IC401 8-759-593-47 IC AK6417AM-E2
(TR618/TR818/TRV49/TRV58/TRV68/TRV78/TRV88/TRV98)
IC401 8-759-640-87 IC BR9016RFV-E2
(TR618E/TR718E/TR728E/TRV49E/
TRV58E/TRV59E/TRV78E/TRV98E)
IC402 8-759-836-63 IC MB91191RPFF-G-166-BND-ER
IC451 8-759-640-85 IC CXA8096R-TBM
IC502 8-759-424-79 IC S-8423YFS-T2
(TRV49/TRV58/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E)
IC502 8-759-660-94 IC NJU7285AV-TE2
(TR618/TR618E/TR718E/TR728E/
TR818/TRV49E/TRV58E/TRV59E)
IC503 8-752-921-65 IC CXP921048A-033R-T6
IC504 8-759-653-63 IC S-817A36ANB-CUZ-T2
IC601 8-759-713-19 IC BH2222FV-E2
< COIL >
L001 1-416-669-11 INDUCTOR 22uH
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
L002 1-416-670-11 INDUCTOR 33uH
L003 1-412-056-11 INDUCTOR 4.7uH
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
L004 1-416-669-11 INDUCTOR 22uH
L005 1-419-354-21 INDUCTOR 22uH
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
VC-251
