CCD-TR618/TR618E/TR718E/TR728E/TR818/TRV49/TRV49E/TRV58/
TRV58E/TRV59E/TRV68/TRV78/TRV78E/TRV88/TRV98/TRV98E
— 44 —
Type M
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
C473 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
(TR618E/TR718E/TR728E/TRV49E/
TRV58E/TRV59E/TRV78E/TRV98E)
C474 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C475 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C476 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C477 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C478 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C479 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C480 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C481 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C482 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C483 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C484 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C501 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C502 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C503 1-126-607-11 ELECT CHIP 47uF 20% 4V
C504 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C506 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C507 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C508 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C509 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C510 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C511 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C512 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C513 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C514 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C515 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C516 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C517 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C518 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C519 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
C601 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C602 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C603 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C701 1-135-639-21 ELECT CHIP 47uF 20% 6.3V
C708 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
(EXCEPT TR818)
< CONNECTOR >
* CN001 1-764-177-11 PIN, CONNECTOR (SMD)(1.5MM) 7P
CN101 1-766-346-21 CONNECTOR, FFC/FPC 16P
CN271 1-779-331-11 CONNECTOR, FFC/FPC 14P
CN301 1-750-360-21 CONNECTOR, FFC/FPC (ZIF) 24P
CN701 1-794-998-21 PIN, CONNECTOR 20P
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
CN702 1-766-350-21 CONNECTOR, FFC/FPC 20P
CN703 1-766-354-21 CONNECTOR, FFC/FPC 24P
CN704 1-766-644-21 CONNECTOR, FFC/FPC 8P
CN706 1-766-340-21 CONNECTOR, FFC/FPC 10P
CN707 1-766-342-21 CONNECTOR, FFC/FPC 12P
CN708 1-779-334-11 CONNECTOR, FFC/FPC 20P (TR818)
CN709 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN710 1-750-076-21 CONNECTOR, FFC/FPC 12P
CN711 1-764-704-21 CONNECTOR, FFC/FPC (LIF) 5P
CN712 1-766-345-21 CONNECTOR, FFC/FPC 15P
CN713 1-774-711-41 CONNECTOR, BOARD TO BOARD 20P
* CN715 1-778-283-11 CONNECTOR, FFC/FPC 4P (EXCEPT TR818)
< DIODE >
D001 8-719-421-27 DIODE MA728-(K8).S0
D002 8-719-062-16 DIODE 01ZA8.2(TPL3)
D004 8-719-073-03 DIODE MA8082-(K8).S0
D005 8-719-078-02 DIODE 1SS357(T3SONY1)
D006 8-719-081-19 DIODE 1SS383(T5RSONY1)
D007 8-719-081-19 DIODE 1SS383(T5RSONY1)
D010 8-719-078-02 DIODE 1SS357(T3SONY1)
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
D151 8-719-081-25 DIODE JDV3C11(TPH3)
D152 8-719-081-25 DIODE JDV3C11(TPH3)
D271 8-719-073-01 DIODE MA111-(K8).S0
(TR618/TR618E/TR718E/TR728E/TRV49/
TRV49E/TRV58/TRV58E/TRV59E)
D272 8-719-082-63 DIODE 1SV329(TPL3)
D301 8-719-073-01 DIODE MA111-(K8).S0
D501 8-719-421-67 DIODE MA132WK-(K8).SO
D503 8-719-421-27 DIODE MA728-(K8).S0
D504 8-719-073-01 DIODE MA111-(K8).S0
D702 8-719-062-16 DIODE 01ZA8.2(TPL3)
< PIN CONNECTOR >
ET101 1-815-032-21 PIN, CONNECTOR (CASE, SHIELD)
ET102 1-815-032-21 PIN, CONNECTOR (CASE, SHIELD)
< FUSE >
0 F001 1-576-406-21 FUSE, MICRO (1.4A) (1608)
0 F002 1-576-406-21 FUSE, MICRO (1.4A) (1608)
0 F003 1-576-406-21 FUSE, MICRO (1.4A) (1608)
0 F004 1-576-406-21 FUSE, MICRO (1.4A) (1608)
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
< FERRITE BEAD >
FB001 1-414-760-21 FERRITE 0UH
FB003 1-414-760-21 FERRITE 0UH
(TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E)
FB101 1-414-228-11 FERRITE 0UH
FB102 1-414-228-11 FERRITE 0UH
FB152 1-414-760-21 FERRITE 0UH
FB153 1-414-760-21 FERRITE 0UH
FB154 1-414-760-21 FERRITE 0UH
FB221 1-414-760-21 FERRITE 0UH
FB271 1-414-760-21 FERRITE 0UH
(TR618/TR618E/TR718E/TR728E/TRV49/
TRV49E/TRV58/TRV58E/TRV59E)
FB273 1-500-284-21 FERRITE 0UH
FB274 1-500-284-21 FERRITE 0UH
FB275 1-414-760-21 FERRITE 0UH
FB276 1-500-284-21 FERRITE 0UH
FB601 1-414-760-21 FERRITE 0UH
To Next Page
