SERVICE MANUAL
SUPPLEMENT-2
File this supplement with the Service Manual.
(PV01-062)
CCD-TR618/TR618E/TR718E/TR728E/TR818
CCD-TRV49/TRV49E/TRV58/TRV58E/TRV59E/TRV68/
TRV78/TRV78E/TRV88/TRV98/TRV98E
RMT-708
US Model
CCD-TR818/TRV58/TRV68/TRV88/TRV98
Canadian Model
CCD-TR818/TRV58/TRV68/TRV98
AEP Model
UK Model
CCD-TR718E/TR728E/TRV58E/
TRV59E/TRV78E/TRV98E
E Model
CCD-TR618/TR618E/TR818/TRV49/
TRV49E/TRV58/TRV68/TRV78/
TRV78E/TRV88/TRV98/TRV98E
Australian Model
CCD-TR618E/TRV49E/TRV78E/TRV98E
Hong Kong Model
CCD-TR618E/TRV49/TRV49E/TRV78/
TRV78E/TRV98/TRV98E
Tourist Model
CCD-TRV49/TRV49E/TRV78/
TRV78E/TRV98/TRV98E
Chinese Model
CCD-TR618E/TRV49E/TRV98E
Brazilian Model
CCD-TR818/TRV58/TRV98
Argentina Model
CCD-TR818/TRV58
Korea Model
CCD-TRV49/TRV78/TRV98
Ver 1.3 2002. 03
• For the method of identifying Type C from Type S, see Section “5. Adjustment,
1-6. LCD System Adjustment, 1. LCD Type Check”.
• There are combinations of the display LCD assembly and the PD-131 board.
Use them in the combination as shown below.
TYPE S
TYPE C
INDICATOR MODULE,
LIQUID CRYST (LCD901)
1-803-852-31
1-803-859-21
PD-131 BOARD, COMPLETE
A-7074-680-A
A-7074-681-A
The display LCD assembly Type C is added to the conventional Type S.
In accordance with the addition of Type C, adjustment and repair parts
list are changed.
