Sony DCR-TRV620E - KP-009

DCR-TRV320/TRV320E/TRV320P/TRV420E/TRV520/TRV520E/TRV520P/TRV525
TRV620E/TRV720/TRV720E
4-85
4-86
USER CONTROL
KP-009
KP-009 (USER CONTROL) PRINTED WIRING BOARD AND SCHEMATIC DIAGRAM
• For Printed Wiring Board.
• There are few cases that the part isn't mounted in this model
is printed on this diagram.
6P
CN301
1
2
3
4
5
6
S302
S305
8200
R302
2200
R304
27k
R301
S301
3900
R303
S304
S303
1
A
REG_GND
KEY_AD5
DIAL_A
DIAL_B
SEIDEN_GND
SEIDEN_GND
EXPOSURE
FADER
SEL/PUSH EXEC
PROGRAM AE
BACK LIGHT
KP-009 BOARD
(DCR-TRV720/TRV720E)
-REF.NO.:20,000 SERIES-
USER CONTROL
CF-72 BOARD
CN009
(THROUGH THE
DP-87 HARNESS)
(SEE PAGE 4-84)
D
C
35
B
E
24
05
F
