Sony DCR-TRV620E - ADJUSTMENTS

– 8 –
DCR-TRV320/TRV320E/TRV320P/TRV420E/TRV520/TRV520E/TRV520P/TRV525
TRV620E/TRV720/TRV720E
SECTION 5
ADJUSTMENTS
• Main Point of Change
PAGE Name of Adjustment Main Point of Change
1-2. INITIALIZATION OF 7, 8, C, D, E, F PAGE DATA AND MODIFICATION OF B PAGE DATA
5-12 5. D Page Table Change of data value
1-5. LCD ELECTRONIC VIEWFINDER SYSTEM ADJUSTMENTS
5-30 2. EVF Initial Data Input (2) Change of data value
5-32 6. Backlight Consumption Current Adjustment Change of adjusting range
1-6. LCD SYSTEM ADJUSTMENTS
5-35 5. Contrast Adjustment Correction
5-36 7. V-COM Adjustment Correction
3-2. SYSTEM CONTROL SYSTEM ADJUSTMENT
5-45 2-2. Input of Serial No. Correction
3-3. SERVO AND RF SYSTEM ADJUSTMENTS
5-48 2. PLL f
0
& LPF f
0
Pre-adjustment Change of specified value and adjusting method
5-50 6. PLL f
0
& LPF f
0
Final Adjustment Change of specified value and adjusting method
4-3. SERVICE MODE
5-66 6. Record of Use Check Correction
- : Points changed portion.
1-2. INITIALIZATION OF 7, 8, C, D, E, F PAGE
DATA AND MODIFICATION OF B PAGE DATA
5. D Page Table
(Service manual page 5-12)
Address
Initial value
Remark
NTSC PAL
90, 91 Fixed data-1 (Initialized data)
92 80 80 VCO adj. (LCD EVF)
93 – 70 Fixed data-1 (NTSC model) /
VCO adj. (LCD EVF) (PAL model)
94 Fixed data-1 (Initialized data)
95 A0 A0 RGB AMP adj. (LCD EVF)
96 Fixed data-1 (Initialized data)
97 80 80 White balance adj. (LCD EVF)
98 80 80
99 30 30 Contrast adj. (LCD EVF)
9A, 9B Fixed data-1 (Initialized data)
9C D0 D0 Backlight consumption current adj.
9D 10 10 (LCD EVF)
9E 90 90
9F Fixed data-2
A0, A1 Fixed data-1 (Initialized data)
A2 80 80 VCO adj. (LCD)
;
=
=
=
